Short-term effectiveness of MAKO robot assisted complex total hip arthroplasty_Chinese Journal of Reparative and Reconstructive Surgery

Authors：

WANG Yang , JI Baochao , CHEN Yongjie ,  LI Guoqing

Department of Joint Surgery, First Affiliated Hospital of Xinjiang Medical University, Urumqi Xinjiang, 830054, P. R. China;

Corresponding?author：

LI Guoqing, Email: 1648255862@qq.com

Keywords：

Total hip arthroplasty; MAKO robot; complex hip disease

DOI：

10.7507/1002-1892.202109054

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

Objective To investigate the short-term effectiveness of MAKO robot assisted complex total hip arthroplasty (THA). Methods The clinical data of 15 patients (17 hips) underwent MAKO robot assisted complex THA between May 2020 and June 2021 were analyzed retrospectively. There were 5 males and 10 females with the age ranged from 19 to 70 years (median, 49 years), included 9 cases (9 hips) of developmental dysplasia of the hip (Crowe type Ⅱ in 5 hips, type Ⅲ in 1 hip, and type Ⅳ in 3 hips), 1 case (2 hips) of rheumatoid arthritis, 2 cases (3 hips) of ankylosing spondylitis, 3 cases (3 hips) of secondary arthritis with a history of acetabular fracture and internal fixation. The acetabular cup abduction angle and anteversion angle were measured at 3 months after operation, and compared with those measured by MAKO robot system before and immediately after operation. The femoral offset and leg length discrepancy (LLD) were measured at 3 months after operation, which were compared with those before operation. Harris hip score (HHS) and visual analogue scale (VAS) score were used to evaluate hip function before operation and at 3 months after operation. Results All 15 patients (17 hips) completed the operation successfully. The operation time was 75-175 minutes, with an average of 116.3 minutes; the intraoperative blood loss was 100-800 mL, with an average of 381.3 mL. Two patients were not included in the statistics because of intraoperative and postoperative complications, the remaining 13 patients (15 hips) had no serious complication such as vascular and nerve injuries, and 3 patients had intermuscular vein thrombosis. The 13 patients (15 hips) were followed up 3-15 months, with an average of 8 months. At last follow-up, the position of prosthesis did not change and there was no signs of loosening. There was no significant difference in acetabular abduction angle at immediate and 3 months after operation when compared with preoperative one (P>0.05), and the acetabular anteversion angle was significantly lower than that before operation (P<0.05). There was no significant difference in acetabular abduction angle and anteversion angle between at immediate and 3 months after operation (P>0.05). The LLD, offset, HHS score, and VAS score were significantly improved at 3 months after operation when compared with preoperative ones (P<0.05). Conclusion MAKO robot assisted complex THA can achieve good short-term effectiveness, improve the hip range of motion, reduce the length difference between bilateral lower limbs, and improve the quality of patients’ life.

Citation： WANG Yang, JI Baochao, CHEN Yongjie, LI Guoqing. Short-term effectiveness of MAKO robot assisted complex total hip arthroplasty. Chinese Journal of Reparative and Reconstructive Surgery, 2022, 36(5): 555-560. doi: 10.7507/1002-1892.202109054 Copy

1.	Caldora P, D’Urso A, Banchetti R, et al. Blood transfusion, hospital stay and learning curve in robotic assisted total hip arthroplasty. J Biol Regul Homeost Agents, 2020, 34(4 Suppl. 3): 37-49.
2.	Kayani B, Konan S, Huq SS, et al. The learning curve of robotic-arm assisted acetabular cup positioning during total hip arthroplasty. Hip Int, 2021, 31(3): 311-319.
3.	Banerjee S, Cherian JJ, Elmallah RK, et al. Robot-assisted total hip arthroplasty. Expert Rev Med Devices, 2016, 13(1): 47-56.
4.	Hadley CJ, Grossman EL, Mont MA, et al. Robotic-assisted versus manually implanted total hip arthroplasty: A clinical and radiographic comparison. Surg Technol Int, 2020, 11(37): 371-376.
5.	Subramanian P, Wainwright TW, Bahadori S, et al. A review of the evolution of robotic-assisted total hip arthroplasty. Hip Int, 2019, 29(3): 232-238.
6.	孔祥朋, 付君, 陳繼營, 等. 5G通信技術遠程指導機器人輔助全髖關節置換術兩例. 中國修復重建外科雜志, 2020, 34(11): 1492-1493.
7.	Perets I, Walsh JP, Close MR, et al. Robot-assisted total hip arthroplasty: Clinical outcomes and complication rate. Int J Med Robot, 2018, 14(4): e1912. doi: 10.1002/rcs.1912.
8.	崔可賾, 郭祥, 陳元良, 等. 后外側入路人工全髖關節置換術中MAKO機器人手臂輔助與傳統人工方法的比較研究. 中國修復重建外科雜志, 2020, 34(7): 883-888.
9.	Chai W, Guo RW, Puah KL, et al. Use of robotic-arm assisted technique in complex primary total hip arthroplasty. Orthop Surg, 2020, 12(2): 686-691.
10.	Boisgard S, Descamps S, Bouillet B. Complex primary total hip arthroplasty. Orthop Traumatol Surg Res, 2013, 99(1 Suppl): S34-S42.
11.	Qin J, Xu Z, Dai J, et al. New technique: practical procedure of robotic arm-assisted (MAKO) total hip arthroplasty. Ann Transl Med, 2018, 6(18): 364. doi: 10.21037/atm.2018.09.30.
12.	Rivière C, Lazennec JY, Van Der Straeten C, et al. The influence of spine-hip relations on total hip replacement: A systematic review. Orthop Traumatol Surg Res, 2017, 103(4): 559-568.
13.	Vigdorchik JM, Sharma AK, Aggarwal VK, et al. The use of robotic-assisted total hip arthroplasty in developmental dysplasia of the hip. Arthroplast Today, 2020, 6(4): 770-776.
14.	Clement ND, Gaston P, Bell A, et al. Robotic arm-assisted versus manual total hip arthroplasty. Bone Joint Res, 2021, 10(1): 22-30.
15.	Ando W, Takao M, Hamada H, et al. Comparison of the accuracy of the cup position and orientation in total hip arthroplasty for osteoarthritis secondary to developmental dysplasia of the hip between the Mako robotic arm-assisted system and computed tomography-based navigation. Int Orthop, 2021, 45(7): 1719-1725.
16.	李俊成, 倪明, 冀全博, 等. 機器人輔助與傳統方法行全髖關節置換術后下肢長度差異比較. 中華骨科雜志, 2021, 41(8): 480-487.
17.	宋平, 孔祥朋, 李想, 等. 機器人輔助全髖關節置換術在伴有髖臼內固定的患者中的應用. 中華外科雜志, 2020, 58(12): 947-950.
18.	郭人文, 孔祥朋, 宋平, 等. CroweⅣ型髖關節發育不良的機器人輔助全髖關節置換術兩例報告. 骨科, 2021, 12(2): 180-182.

1. Caldora P, D’Urso A, Banchetti R, et al. Blood transfusion, hospital stay and learning curve in robotic assisted total hip arthroplasty. J Biol Regul Homeost Agents, 2020, 34(4 Suppl. 3): 37-49.
2. Kayani B, Konan S, Huq SS, et al. The learning curve of robotic-arm assisted acetabular cup positioning during total hip arthroplasty. Hip Int, 2021, 31(3): 311-319.
3. Banerjee S, Cherian JJ, Elmallah RK, et al. Robot-assisted total hip arthroplasty. Expert Rev Med Devices, 2016, 13(1): 47-56.
4. Hadley CJ, Grossman EL, Mont MA, et al. Robotic-assisted versus manually implanted total hip arthroplasty: A clinical and radiographic comparison. Surg Technol Int, 2020, 11(37): 371-376.
5. Subramanian P, Wainwright TW, Bahadori S, et al. A review of the evolution of robotic-assisted total hip arthroplasty. Hip Int, 2019, 29(3): 232-238.
6. 孔祥朋, 付君, 陳繼營, 等. 5G通信技術遠程指導機器人輔助全髖關節置換術兩例. 中國修復重建外科雜志, 2020, 34(11): 1492-1493.
7. Perets I, Walsh JP, Close MR, et al. Robot-assisted total hip arthroplasty: Clinical outcomes and complication rate. Int J Med Robot, 2018, 14(4): e1912. doi: 10.1002/rcs.1912.
8. 崔可賾, 郭祥, 陳元良, 等. 后外側入路人工全髖關節置換術中MAKO機器人手臂輔助與傳統人工方法的比較研究. 中國修復重建外科雜志, 2020, 34(7): 883-888.
9. Chai W, Guo RW, Puah KL, et al. Use of robotic-arm assisted technique in complex primary total hip arthroplasty. Orthop Surg, 2020, 12(2): 686-691.
10. Boisgard S, Descamps S, Bouillet B. Complex primary total hip arthroplasty. Orthop Traumatol Surg Res, 2013, 99(1 Suppl): S34-S42.
11. Qin J, Xu Z, Dai J, et al. New technique: practical procedure of robotic arm-assisted (MAKO) total hip arthroplasty. Ann Transl Med, 2018, 6(18): 364. doi: 10.21037/atm.2018.09.30.
12. Rivière C, Lazennec JY, Van Der Straeten C, et al. The influence of spine-hip relations on total hip replacement: A systematic review. Orthop Traumatol Surg Res, 2017, 103(4): 559-568.
13. Vigdorchik JM, Sharma AK, Aggarwal VK, et al. The use of robotic-assisted total hip arthroplasty in developmental dysplasia of the hip. Arthroplast Today, 2020, 6(4): 770-776.
14. Clement ND, Gaston P, Bell A, et al. Robotic arm-assisted versus manual total hip arthroplasty. Bone Joint Res, 2021, 10(1): 22-30.
15. Ando W, Takao M, Hamada H, et al. Comparison of the accuracy of the cup position and orientation in total hip arthroplasty for osteoarthritis secondary to developmental dysplasia of the hip between the Mako robotic arm-assisted system and computed tomography-based navigation. Int Orthop, 2021, 45(7): 1719-1725.
16. 李俊成, 倪明, 冀全博, 等. 機器人輔助與傳統方法行全髖關節置換術后下肢長度差異比較. 中華骨科雜志, 2021, 41(8): 480-487.
17. 宋平, 孔祥朋, 李想, 等. 機器人輔助全髖關節置換術在伴有髖臼內固定的患者中的應用. 中華外科雜志, 2020, 58(12): 947-950.
18. 郭人文, 孔祥朋, 宋平, 等. CroweⅣ型髖關節發育不良的機器人輔助全髖關節置換術兩例報告. 骨科, 2021, 12(2): 180-182.
