Short-term effectiveness of free radial head reconstruction of coronoid process combined with artificial radial head replacement in treatment of complex terrible triad of elbow_Chinese Journal of Reparative and Reconstructive Surgery

Authors：

CHEN Tao ^1,2 ,  MA Xinlong ³ , MA Jianxiong ³ , YU Runze ² , YU Defu ²

1. Postgraduate Institute, Tianjin Medical University, Tianjin, 300070, P.R.China;
2. Department of Orthopaedics, Anhui No.2 Provincal People’s Hospital, Hefei Anhui, 230041, P.R.China;
3. Institute of Orthopedics, Tianjin Hospital, Tianjin, 300211, P.R.China;

Corresponding?author：

MA Xinlong, Email: tjmxl2017@sina.com

Keywords：

Terrible triad of the elbow; free radial head fragment; coronal process reconstruction; radial head replacement

DOI：

10.7507/1002-1892.202009081

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

Objective To investigate the short-term effectiveness of free radial head reconstruction of coronoid process, artificial radial head replacement, and ulna olecranon internal fixation in the treatment of the complex terrible triad of the elbow.Methods Retrospective analysis was made on the clinical data of 12 patients with complex terrible triad of the elbow treated with free radial head reconstruction of coronoid process, artificial radial head replacement, and ulna olecranon internal fixation between April 2011 and April 2018. There were 8 males and 4 females with an average age of 44.5 years (range, 26-62 years). The causes of injury included 5 cases of traffic accident, 7 cases of falling from hight. The Regan-Morrey classification of ulnar coronoid process fractures was type Ⅲ; Mason classification of radial head fractures was type Ⅲ in 7 cases and type Ⅳ in 5 cases. The time from injury to operation was 5-14 days, with an average of 6.0 days. The operation time, intraoperative blood loss, and complications were recorded. After operation, X-ray film of elbow joint was reexamined, fracture healing condition was observed, and fracture healing time was recorded. The flexion, extension, and rotation of the elbow joints on the healthy and affected sides were recorded and measured. The elbow function was evaluated according to Mayo elbow function score.Results The operation time was 90-140 minutes (mean, 110 minutes); the intraoperative blood loss was 100-300 mL (mean, 150 mL). None of the patients had vascular injury during the operation. One patient developed numbness in the ulnar nerve innervation area and recovered completely after symptomatic treatment for 1 week. All the 12 patients were followed up 12-22 months, with an average of 16 months. At last follow-up, the fracture healed completely, 1 patient developed ectopic ossification of elbow joint, and 2 patients developed traumatic arthritis of elbow joint. No internal fixation-related complications occurred. There was no significant difference in the range of motion of elbow flexion, extension, pronation, and supination between the affected and healthy sides (P>0.05). The median Mayo elbow function score was 96, and the interquartile range was (94, 97), and the excellent and good rate was 91.7%.Conclusion For patients with complex terrible triad of the elbow with ulna coronoid process fractures of Regan-Morrey type Ⅲ and radial head fractures of Mason type Ⅲ, Ⅳ combined with ulna olecranon fractures, the free radial head reconstruction, artificial radial head replacement, and ulna olecranon internal fixation, through active rehabilitation function exercise after operation, can achieve more satisfactory short-term effectiveness.

Citation： CHEN Tao, MA Xinlong, MA Jianxiong, YU Runze, YU Defu. Short-term effectiveness of free radial head reconstruction of coronoid process combined with artificial radial head replacement in treatment of complex terrible triad of elbow. Chinese Journal of Reparative and Reconstructive Surgery, 2021, 35(2): 139-143. doi: 10.7507/1002-1892.202009081 Copy

1.	Kani KK, Chew FS. Terrible triad injuries of the elbow. Emerg Radiol, 2019, 26(3): 341-347.
2.	Li S, Li X, Lu Y. Analysis of radial head and coronoid process fractures in terrible triad of elbow. Eur J Orthop Surg Traumatol, 2019, 29(4): 775-784.
3.	肖刻, 張嘉, 李濤, 等. 肘關節 “恐怖三聯征” 的解剖、治療及其命名合理性的探討. 中華骨科雜志, 2015, 35(7): 781-786.
4.	Liu G, Hu J, Ma W, et al. Surgical treatment for terrible triad injury of the elbow with anteromedial coronoid fracture through a combined surgical approach. J Int Med Res, 2018, 46(8): 3053-3064.
5.	álvarez Mu?oz M, Pardo García JM, García Lamas L, et al. Protocolised surgical treatment of terrible triad of elbow. Results and complications. Rev Esp Cir Ortop Traumatol, 2019, 63(4): 281-288.
6.	Cusick MC, Bonnaig NS, Azar FM, et al. Accuracy and reliability of the Mayo Elbow Performance Score. J Hand Surg (Am), 2014, 39(6): 1146-1150.
7.	Galbiatti JA, Cardoso FL, Ferro JA, et al. Terrible triad of the elbow: evaluation of surgical treatment. Rev Bras Ortop, 2018, 53(4): 460-466.
8.	Jung SW, Kim DH, Kang SH, et al. Risk factors that influence subsequent recurrent instability in terrible triad injury of the elbow. J Orthop Trauma, 2019, 33(5): 250-255.
9.	公茂琪, 蔣協遠. 肘關節損傷三聯征的治療. 中華骨科雜志, 2018, 38(1): 60-64.
10.	王華松, 吳剛, 劉曦明, 等. 肘前入路微型鋼板內固定治療尺骨冠狀突骨折. 中華創傷雜志, 2018, 34(4): 345-350.
11.	Antoni M, Eichler D, Kempf JF, et al. Anterior capsule re-attachment in terrible triad elbow injury with coronoid tip fracture. Orthop Traumatol Surg Res, 2019, 105(8): 1575-1583.
12.	Regan W, Morrey B. Fractures of the coronoid process of the ulna. J Bone Joint Surg (Am), 1989, 71(9): 1348-1354.
13.	向明, 楊國勇, 胡曉川, 等. 肘關節前方血管神經間入路治療尺骨冠狀突骨折的中期研究. 中華骨科雜志, 2018, 38(1): 8-15.
14.	朱刃, 周均明, 趙興, 等. 改良肘關節前側入路治療尺骨冠狀突骨折. 中華創傷雜志, 2015, 31(5): 331-334.
15.	Ring D, Guss D, Jupiter JB. Reconstruction of the coronoid process using a fragment of discarded radial head. J Hand Surg (Am), 2012, 37(3): 570-574.
16.	Moritomo H, Tada K, Yoshida T, et al. Reconstruction of the coronoid for chronic dislocation of the elbow. J Bone Joint Surg (Br), 1998, 80(3): 490-492.
17.	Mason ML. Some observations on fractures of the head of the radius with a review of one hundred cases. Br J Surg, 1954, 42(172): 123-132.
18.	公茂琪, 黃曉文, 李國珅, 等. 單一外側切口和內外側雙切口治療肘關節三聯征的對比研究. 中華創傷雜志, 2017, 33(5): 389-396.
19.	查曄軍, 蔣協遠, 公茂琪. 保守治療無骨性阻擋的 Mason Ⅱ、Ⅲ 型橈骨頭骨折的療效. 中華骨科雜志, 2018, 38(1): 16-22.
20.	Klug A, Nagy A, Gramlich Y, et al. Surgical treatment of the radial head in terrible triad injuries of the elbow. Bone Joint J, 2020, 102-B(12): 1618-1619.
21.	Afifi A, Lymona AM, Galal S. Radial head fixation vs replacement in terrible triad: Preliminary results of a prospective cohort study with patient reported outcome. Indian J Orthop, 2020, 54(Suppl 2): 254-259.
22.	Mukka S, Sj?holm P, Perisynakis N, et al. Radial head arthroplasty for radial head fractures: a clinical and radiological comparison of monopolar and bipolar radial head arthroplasty at a mean follow-up of 6 years. Eur J Trauma Emerg Surg, 2020, 46(3): 565-572.

1. Kani KK, Chew FS. Terrible triad injuries of the elbow. Emerg Radiol, 2019, 26(3): 341-347.
2. Li S, Li X, Lu Y. Analysis of radial head and coronoid process fractures in terrible triad of elbow. Eur J Orthop Surg Traumatol, 2019, 29(4): 775-784.
3. 肖刻, 張嘉, 李濤, 等. 肘關節 “恐怖三聯征” 的解剖、治療及其命名合理性的探討. 中華骨科雜志, 2015, 35(7): 781-786.
4. Liu G, Hu J, Ma W, et al. Surgical treatment for terrible triad injury of the elbow with anteromedial coronoid fracture through a combined surgical approach. J Int Med Res, 2018, 46(8): 3053-3064.
5. álvarez Mu?oz M, Pardo García JM, García Lamas L, et al. Protocolised surgical treatment of terrible triad of elbow. Results and complications. Rev Esp Cir Ortop Traumatol, 2019, 63(4): 281-288.
6. Cusick MC, Bonnaig NS, Azar FM, et al. Accuracy and reliability of the Mayo Elbow Performance Score. J Hand Surg (Am), 2014, 39(6): 1146-1150.
7. Galbiatti JA, Cardoso FL, Ferro JA, et al. Terrible triad of the elbow: evaluation of surgical treatment. Rev Bras Ortop, 2018, 53(4): 460-466.
8. Jung SW, Kim DH, Kang SH, et al. Risk factors that influence subsequent recurrent instability in terrible triad injury of the elbow. J Orthop Trauma, 2019, 33(5): 250-255.
9. 公茂琪, 蔣協遠. 肘關節損傷三聯征的治療. 中華骨科雜志, 2018, 38(1): 60-64.
10. 王華松, 吳剛, 劉曦明, 等. 肘前入路微型鋼板內固定治療尺骨冠狀突骨折. 中華創傷雜志, 2018, 34(4): 345-350.
11. Antoni M, Eichler D, Kempf JF, et al. Anterior capsule re-attachment in terrible triad elbow injury with coronoid tip fracture. Orthop Traumatol Surg Res, 2019, 105(8): 1575-1583.
12. Regan W, Morrey B. Fractures of the coronoid process of the ulna. J Bone Joint Surg (Am), 1989, 71(9): 1348-1354.
13. 向明, 楊國勇, 胡曉川, 等. 肘關節前方血管神經間入路治療尺骨冠狀突骨折的中期研究. 中華骨科雜志, 2018, 38(1): 8-15.
14. 朱刃, 周均明, 趙興, 等. 改良肘關節前側入路治療尺骨冠狀突骨折. 中華創傷雜志, 2015, 31(5): 331-334.
15. Ring D, Guss D, Jupiter JB. Reconstruction of the coronoid process using a fragment of discarded radial head. J Hand Surg (Am), 2012, 37(3): 570-574.
16. Moritomo H, Tada K, Yoshida T, et al. Reconstruction of the coronoid for chronic dislocation of the elbow. J Bone Joint Surg (Br), 1998, 80(3): 490-492.
17. Mason ML. Some observations on fractures of the head of the radius with a review of one hundred cases. Br J Surg, 1954, 42(172): 123-132.
18. 公茂琪, 黃曉文, 李國珅, 等. 單一外側切口和內外側雙切口治療肘關節三聯征的對比研究. 中華創傷雜志, 2017, 33(5): 389-396.
19. 查曄軍, 蔣協遠, 公茂琪. 保守治療無骨性阻擋的 Mason Ⅱ、Ⅲ 型橈骨頭骨折的療效. 中華骨科雜志, 2018, 38(1): 16-22.
20. Klug A, Nagy A, Gramlich Y, et al. Surgical treatment of the radial head in terrible triad injuries of the elbow. Bone Joint J, 2020, 102-B(12): 1618-1619.
21. Afifi A, Lymona AM, Galal S. Radial head fixation vs replacement in terrible triad: Preliminary results of a prospective cohort study with patient reported outcome. Indian J Orthop, 2020, 54(Suppl 2): 254-259.
22. Mukka S, Sj?holm P, Perisynakis N, et al. Radial head arthroplasty for radial head fractures: a clinical and radiological comparison of monopolar and bipolar radial head arthroplasty at a mean follow-up of 6 years. Eur J Trauma Emerg Surg, 2020, 46(3): 565-572.
