Study on sustentaculum tali screw placement for constant fragment of calcaneal fracture_Chinese Journal of Reparative and Reconstructive Surgery

Authors：

SUN Zhenhui ¹ , ZHAO Chengli ² , CHEN Yifei ² , LI Nan ¹ , ZHANG Tao ¹ , XIN Jingyi ¹ ,  MA Xinlong ¹

1. Department of Orthopaedics, Tianjin Hospital, Tianjin, 300211, P.R.China;
2. Department of Orthopaedics, Xiqing Hospital of Tianjing, Tianjin, 300000, P.R.China;

Corresponding?author：

MA Xinlong, Email: maxinlong8686@sina.com

Keywords：

Calcaneal fracture; constant fragment; sustentaculum tali; screw placement; entry point

DOI：

10.7507/1002-1892.201801041

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

ObjectiveTo investigate the anatomical characters of the sustentaculum tali (ST), accurate entry point and direction for the placement of ST screw from posterior subtalar joint facet to the constant fragment (CF) in calcaneal fractures.MethodsA total of 100 patients with calcaneal fractures performed ankle CT scans were enrolled between January 2016 and April 2016. According to the inclusion criteria, the clinical data of 33 patients were analyzed, including 18 males and 15 females, with a median age of 41.0 years (range, 18-60 years). There were 16 cases on left side and 17 cases on the right side. Three-dimensional (3D) calcaneal model was reconstructed by Mimics 17.0 software, and the ST anatomical references were measured, including the length of upper and lower edge, the length and height of the midline, the horizontal angle between the midline and foot plantar surface. The parameters of the optimal entry point position (P’ point) and placement angle of the ST screw were determined. The length of ST screw was also measured. The differences between males and females or left and right sides were compared.ResultsThe length of upper edge of the ST was (16.60±2.23) mm, lower edge (20.65±2.90) mm, midline (20.56±2.62) mm, and the height of midline was (9.61±1.36) mm. The horizontal angle between the midline and foot plantar surface was (23.43±3.36)°. The vertical distance from P’ point to the lowest point of the tarsal sinus was (3.09±1.65) mm, while the horizontal distance was (14.29±2.75) mm. The distance from P’ point to the apex of the lateral talus, subchondral bone of subtalar joint, calcaneocuboid joint was (11.41±3.22), (6.59±2.22), (34.58±3.75) mm, respectively. The horizontal angle between the ST screw and foot plantar surface was (–1.17±2.07)°. The anteversion angle of ST screw was (16.18±2.05)° and the length was (41.64 ± 3.09) mm. There were significant differences in the length of upper and lower edge, the length and height of the midline, the distance from P’ point to the apex of the lateral talus, subchondral bone of subtalar joint, and calcaneocuboid joint, and the anteversion angle and length of the ST screw between males and females (P<0.05). There was no significant difference in above all parameters between left and right sides (P>0.05).ConclusionAfter appropriate reduction of the calcaneal fractures, the entry point of ST screw was recommended at about 14 mm posterior and about 3 mm upper related to the foot horizontal line through the lowest tarsal sinus point; and the direction of ST screw placement was about 17° anteversion for males and 15° anteversion for females.
