Evaluation of Low-field MR in the Diagnosis of Excessive Lateral Pressure Syndrome for Patellofemoral Joint_West China Medical Journal

Authors：

 CHENBing ,  CHENJun-rong , LUORong-zhi , HUANGYun-jie , LIXu-xue

Department of Radiology, Sichuan Orthopedics Hospital, Chengdu, Sichuan 610041, P. R. China;

Corresponding?author：

CHENJun-rong, Email: kevinjrchen@163.com

Keywords：

Patellofemoral joint; Excessive lateral pressure syndrome; Magnetic resonance imaging

DOI：

10.7507/1002-0179.20140683

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

Objective To investigate the value and feasibility of low-field MR in the diagnosis of excessive lateral pressure syndrome (ELPS) of the patellofemoral joint. Methods Thirty-seven patients confirmed to have ELPS by surgery or clinical examination between March 2010 and March 2013 were involved in this retrospective study. The injured knees of all patients were examined by SE sequence and Fat sequence, using Siemens 0.35 T MR scanner. The patella was assessed. Infrapatellar fat pad, patella tilt angle and patellofemoral joint space were measured. Results There were 15 cases of type Ⅱ, 21 of type Ⅲ, and 1 of type Ⅳ knees. Three cases of bipartite were detected. Patella tilt angle: type Ⅳ > type Ⅲ > type Ⅱ. Infrapatellar fat pad had edema in 37 cases. And there were 29 cases of varying degrees of lateral patellar cartilage softening. Conclusion Low-field MRI is an effective diagnostic method of excessive lateral pressure syndrome for patellofemoral joint. STIR sequence is the best sequence for diagnosing patellofemoral excessive lateral pressure syndrome.

Citation： CHENBing, CHENJun-rong, LUORong-zhi, HUANGYun-jie, LIXu-xue. Evaluation of Low-field MR in the Diagnosis of Excessive Lateral Pressure Syndrome for Patellofemoral Joint. West China Medical Journal, 2014, 29(12): 2259-2262. doi: 10.7507/1002-0179.20140683 Copy

1.	舒從科, 楊本伍, 關鈦元, 等. 關節鏡下治療髕股外側高壓綜合征[J]. 骨科, 2013, 4(2):94-96.
2.	劉勁松, 張道平. 髕股外側高壓綜合征的研究現狀[J]. 中國骨傷, 2011, 24(5):436-441.
3.	Chung CB, Skaf A, Roger B, et al. Patellar tendon-lateral femoral condyle friction syndrome:Mr imaging in 42 patients[J]. Skeletal Radiol, 2001, 30(12):694-697.
4.	Wiberg G. Roentgenographic and anatomic studies on the femoropatellar joint, with special reference to chondromalacia patellae[J]. Acta Orthop Scand, 1941, 12:319-410.
5.	Brittberg M, Winalski CS. Evaluation of cartilage injuries and repair[J]. J Bone Joint Surg Am, 2003, 85-A(Suppl 2):58-69.
6.	Fithian DC, Paxton EW, Stone ML, et al. Epidemiology and natural history of acute patellar dislocation[J]. Am J Sports Med, 2004, 32(5):1114-1121.
7.	Nomura E, Inoue M. Cartilage lesions of the patella in recurrent patellar dislocation[J]. Am J Sports Med, 2004, 32(2):498-502.
8.	Fulkerson JP. 髕股關節疾病的診斷與治療[M]. 4版. 裴福興, 譯. 北京:人民衛生出版社, 2006:24.
9.	Amis AA, Senavongse W, Bull AM. Patellofemoral kinematics during knee flexion-extension:an in vitro study[J]. J Orthop Res, 2006, 24(12):2201-2211.
10.	Davis DK, Fithian DC. Techniques of medial retinacular repair and reconstruction[J]. Clin Orthop Relat Res, 2002(42):38-52.
11.	Panagiotopoulos E, Strzelczyk P, Herrmann M, et al. Cadaveric study on static medial patellar stabilizers:the dynamizing role of the vastus medialis obliquus on medial patellofemoral ligament[J]. Knee Surg Sports Traumatol Arthrosc, 2006, 14(1):7-12.
12.	Merican AM, Amis AA. Anatomy of the lateral retinaculum of the knee[J]. J Bone Joint Surg Br, 2008, 90(4):527-534.
13.	張有磊. 髕骨傾斜與外側高壓綜合征的研究進展[J]. 中國骨與關節雜志, 2014, 3(6):455-459.
14.	劉兆芹, 錢學江. 髕骨軟化癥的關節鏡分級診斷與影像學對比分析[J]. 實用醫藥雜志, 2010, 27(7):610-611.
15.	王娟, 張家雄, 周守國. Hoffa病與髕骨運動軌跡異常相關性的MRI研究[J]. 放射學實踐, 2014, 29(4):428-432.

1. 舒從科, 楊本伍, 關鈦元, 等. 關節鏡下治療髕股外側高壓綜合征[J]. 骨科, 2013, 4(2):94-96.
2. 劉勁松, 張道平. 髕股外側高壓綜合征的研究現狀[J]. 中國骨傷, 2011, 24(5):436-441.
3. Chung CB, Skaf A, Roger B, et al. Patellar tendon-lateral femoral condyle friction syndrome:Mr imaging in 42 patients[J]. Skeletal Radiol, 2001, 30(12):694-697.
4. Wiberg G. Roentgenographic and anatomic studies on the femoropatellar joint, with special reference to chondromalacia patellae[J]. Acta Orthop Scand, 1941, 12:319-410.
5. Brittberg M, Winalski CS. Evaluation of cartilage injuries and repair[J]. J Bone Joint Surg Am, 2003, 85-A(Suppl 2):58-69.
6. Fithian DC, Paxton EW, Stone ML, et al. Epidemiology and natural history of acute patellar dislocation[J]. Am J Sports Med, 2004, 32(5):1114-1121.
7. Nomura E, Inoue M. Cartilage lesions of the patella in recurrent patellar dislocation[J]. Am J Sports Med, 2004, 32(2):498-502.
8. Fulkerson JP. 髕股關節疾病的診斷與治療[M]. 4版. 裴福興, 譯. 北京:人民衛生出版社, 2006:24.
9. Amis AA, Senavongse W, Bull AM. Patellofemoral kinematics during knee flexion-extension:an in vitro study[J]. J Orthop Res, 2006, 24(12):2201-2211.
10. Davis DK, Fithian DC. Techniques of medial retinacular repair and reconstruction[J]. Clin Orthop Relat Res, 2002(42):38-52.
11. Panagiotopoulos E, Strzelczyk P, Herrmann M, et al. Cadaveric study on static medial patellar stabilizers:the dynamizing role of the vastus medialis obliquus on medial patellofemoral ligament[J]. Knee Surg Sports Traumatol Arthrosc, 2006, 14(1):7-12.
12. Merican AM, Amis AA. Anatomy of the lateral retinaculum of the knee[J]. J Bone Joint Surg Br, 2008, 90(4):527-534.
13. 張有磊. 髕骨傾斜與外側高壓綜合征的研究進展[J]. 中國骨與關節雜志, 2014, 3(6):455-459.
14. 劉兆芹, 錢學江. 髕骨軟化癥的關節鏡分級診斷與影像學對比分析[J]. 實用醫藥雜志, 2010, 27(7):610-611.
15. 王娟, 張家雄, 周守國. Hoffa病與髕骨運動軌跡異常相關性的MRI研究[J]. 放射學實踐, 2014, 29(4):428-432.
