Application of automatic injection device based on automatic hemostasis in injection of radiopharmaceutical bolus injection_Journal of Biomedical Engineering

Authors：

 LI Jin ^1,2 , FAN Wenhong ³ , MA Jianxiong ¹ , ZHOU Wei ² , PANG Xinxin ² , TIAN Cungui ² , YANG Guohui ² , WANG Yan ¹ , ZHAO Na ²

1. Tianjin Hospital, Tianjin University, Tianjin 300211, P. R. China;
2. CNNC High Energy Equipment (Tianjin) Co., Ltd., Tianjin 300300, P. R. China;
3. Tianjin Medical University General Hospital, Tianjin 300052, P. R. China;

Corresponding?author：

LI Jin, Email: mjx969@163.com

Keywords：

Radiopharmaceutical dynamic imaging; Bolus injection; Automatic injection device

DOI：

10.7507/1001-5515.202301013

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

In clinical practice, radiopharmaceutical dynamic imaging technology requires the bolus injection method to complete injection. Due to the failure rate and radiation damage of manual injection, even experienced technicians still bear a lot of psychological burden. This study combined the advantages and disadvantages of various manual injection modes to develop the radiopharmaceutical bolus injector, and explored the application of automatic injection in the field of bolus injection from four aspects: radiation protection, occlusion response, sterility of injection process and effect of bolus injection. Compared with the current mainstream manual injection method, the bolus manufactured by the radiopharmaceutical bolus injector based on the automatic hemostasis method had a narrower full width at half maximum and better repeatability. At the same time, radiopharmaceutical bolus injector had reduced the radiation dose of the technician’s palm by 98.8%, and ensured more efficient vein occlusion recognition performance and sterility of the entire injection process. The radiopharmaceutical bolus injector based on automatic hemostasis has application potential in improving the effect and repeatability of bolus injection.
