Rapid femur modeling method based on statistical shape model_Journal of Biomedical Engineering

Authors：

ZHANG Zhiwei ¹ , CHEN Zhenxian ² , ZHANG Zhifeng ³ , WANG Caimei ⁴ ,  JIN Zhongmin ^1,5

1. International Machinery Center, Xi’an Jiaotong University, Xi’an 710049, P. R. China;
2. School of Mechanical Engineering, Chang’an University, Xi’an 710064, P. R. China;
3. The Second Affiliated Hospital of Inner Mongolia Medical University, Hohhot 010050, P. R. China;
4. Beijing AK Medical Co., LTD, Beijing 102299, P. R. China;
5. School of Mechanical Engineering, Southwest Jiaotong University, Chengdu 610031, P. R. China;

Corresponding?author：

JIN Zhongmin, Email: zmjin@xjtu.edu.cn

Keywords：

Bone geometry; Three-dimensional reconstruction; Statistical shape model; Rapid modeling

DOI：

10.7507/1001-5515.202111005

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

The geometric bone model of patients is an important basis for individualized biomechanical modeling and analysis, formulation of surgical planning, design of surgical guide plate, and customization of artificial joint. In this study, a rapid three-dimensional (3D) reconstruction method based on statistical shape model was proposed for femur. Combined with the patient plain X-ray film data, rapid 3D modeling of individualized patient femur geometry was realized. The average error of 3D reconstruction was 1.597–1.842 mm, and the root mean square error was 1.453–2.341 mm. The average errors of femoral head diameter, cervical shaft angle, offset distance and anteversion angle of the reconstructed model were 0.597 mm, 1.163°, 1.389 mm and 1.354°, respectively. Compared with traditional modeling methods, the new method could achieve rapid 3D reconstruction of femur more accurately in a shorter time. This paper provides a new technology for rapid 3D modeling of bone geometry, which is helpful to promote rapid biomechanical analysis for patients, and provides a new idea for the selection of orthopedic implants and the rapid research and development of customized implants.

Citation： ZHANG Zhiwei, CHEN Zhenxian, ZHANG Zhifeng, WANG Caimei, JIN Zhongmin. Rapid femur modeling method based on statistical shape model. Journal of Biomedical Engineering, 2022, 39(5): 862-869. doi: 10.7507/1001-5515.202111005 Copy
