Fatigue analysis of upper limb rehabilitation based on surface electromyography signal and motion capture_Journal of Biomedical Engineering

Authors：

XU Zhao ,  LU Jian , PAN Weijie , HE Kailun

Key Laboratory of Advanced Manufacturing Technology of the Ministry of Education, Guizhou University, Guiyang 550025, P. R. China;

Corresponding?author：

LU Jian, Email: 305515940@qq.com

Keywords：

Electromyography fatigue threshold; Motion capture; Biomechanics; Upper limb fatigue analysis

DOI：

10.7507/1001-5515.202108026

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

At present, fatigue state monitoring of upper limb movement generally relies solely on surface electromyographic signal (sEMG) to identify and classify fatigue, resulting in unstable results and certain limitations. This paper introduces the sEMG signal recognition and motion capture technology into the fatigue state monitoring process and proposes a fatigue analysis method combining an improved EMG fatigue threshold algorithm and biomechanical analysis. In this study, the right upper limb load elbow flexion test was used to simultaneously collect the biceps brachii sEMG signal and upper limb motion capture data, and at the same time the Borg Fatigue Subjective and Self-awareness Scale were used to record the fatigue feelings of the subjects. Then, the fatigue analysis method combining the EMG fatigue threshold algorithm and the biomechanical analysis was combined with four single types: mean power frequency (MPF), spectral moments ratio (SMR), fuzzy approximate entropy (fApEn) and Lempel-Ziv complexity (LZC). The test results of the evaluation index fatigue evaluation method were compared. The test results show that the method in this paper has a recognition rate of 98.6% for the overall fatigue state and 97%, 100%, and 99% for the three states of ease, transition and fatigue, which are more advantageous than other methods. The research results of this paper prove that the method in this paper can effectively prevent secondary injury caused by overtraining during upper limb exercises, and is of great significance for fatigue monitoring.

Citation： XU Zhao, LU Jian, PAN Weijie, HE Kailun. Fatigue analysis of upper limb rehabilitation based on surface electromyography signal and motion capture. Journal of Biomedical Engineering, 2022, 39(1): 92-102. doi: 10.7507/1001-5515.202108026 Copy
