Design and mechanical properties of biodegradable polymeric stent_Journal of Biomedical Engineering

Authors：

CHEN Yu ¹ , WANG Guanshi ¹ , CHEN Chong ¹ , SUN Anqiang ² , FENG Wentao ² ,  JIANG Wentao ¹

1. Department of Mechanical Science and Engineering, Sichuan University, Chengdu 610065, P.R.China;
2. School of Biological Science and Medical Engineering, Beihang University, Beijing 100191, P.R.China;

Corresponding?author：

Keywords：

biodegradable; polymer; stent; configuration; mechanical properties

DOI：

10.7507/1001-5515.202009039

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

Biodegradable stents (BDSs) are the milestone in percutaneous coronary intervention(PCI). Biodegradable polymeric stents have received widespread attention due to their good biocompatibility, moderate degradation rate and degradation products without toxicity or side effects. However, due to the defects in mechanical properties of polymer materials, the clinical application of polymeric BDS has been affected. In this paper, the BDS geometric configuration design was analyzed to improve the radial strength, flexibility and reduce the shrinkage rate of biodegradable polymeric stents. And from the aspects of numerical simulation, in vitro experiment and animal experiment, the configuration design and mechanical properties of biodegradable polymeric stents were introduced in detail in order to provide further references for the development of biodegradable polymeric stents.

Citation： CHEN Yu, WANG Guanshi, CHEN Chong, SUN Anqiang, FENG Wentao, JIANG Wentao. Design and mechanical properties of biodegradable polymeric stent. Journal of Biomedical Engineering, 2020, 37(6): 967-973. doi: 10.7507/1001-5515.202009039 Copy
