Research Progress and Prospect of Applications of Finite Element Method in Lumbar Spine Biomechanics_Journal of Biomedical Engineering

Authors：

ZHANGZhenjun ^1,2 , LIYang ^1,2 , LIAOZhenhua ^1,3 ,  LIUWeiqiang ^2,3

1. Department of Mechanical Engineering, Tsinghua University, Beijing 100084, China;
2. State Key Laboratory of Tribology, Tsinghua University, Beijing 100084, China;
3. Shenzhen Institute of Tsinghua University, Laboratory of Biomedical Material and Implanted Devices, Shenzhen 518057, China;

Corresponding?author：

LIUWeiqiang, Email: weiqliu@hotmail.com

Keywords：

finite element method; lumbar; biomechanics; fusion; artificial lumbar disc replacement

DOI：

10.7507/1001-5515.20160189

Video：

Export PDF Favorites Scan Get Citation

Abstract Full text Figures/Tables Video References Cited by

Based on the application of finite element analysis in spine biomechanics, the research progress of finite element method applied in lumbar spine mechanics is reviewed and the prospect is forecasted. The related works, including lumbar ontology modeling, clinical application research, and occupational injury and protection, are summarized. The main research areas of finite element method are as follows: new accurate modeling process, the optimized simulation method, diversified clinical effect evaluation, and the clinical application of artificial lumbar disc. According to the recent research progress, the application prospects of finite element method, such as automation and individuation of modeling process, evaluation and analysis of new operation methods and simulation of mechanical damage and dynamic response, are discussed. The purpose of this paper is to provide the theoretical reference and practical guidance for the clinical lumbar problems by reviewing the application of finite element method in the field of the lumbar spine biomechanics.

Citation： ZHANGZhenjun, LIYang, LIAOZhenhua, LIUWeiqiang. Research Progress and Prospect of Applications of Finite Element Method in Lumbar Spine Biomechanics. Journal of Biomedical Engineering, 2016, 33(6): 1196-1202. doi: 10.7507/1001-5515.20160189 Copy
